11.8.4 Signals
SEMOD53803-1 v2
PID-3819-INPUTSIGNALS v5
Table 358: RANGE_XP Input signals
Name
Type Default Description
RANGE INTEGER 0 Measured value range
PID-3819-OUTPUTSIGNALS v5
Table 359: RANGE_XP Output signals
Name Type Description
HIGHHIGH BOOLEAN Measured value is above high-high limit
HIGH BOOLEAN Measured value is between high and high-high
limit
NORMAL BOOLEAN Measured value is between high and low limit
LOW BOOLEAN Measured value is between low and low-low limit
LOWLOW BOOLEAN Measured value is below low-low limit
11.8.5 Operation principle
SEMOD52462-4 v5
The input signal must be connected to a range output of a measuring function block
(CVMMXN, CMMXU, VMMXU, VNMMXU, CMSQI, VMSQ or MVGAPC).
The function block converts the input integer value to five binary output signals
according to
table 360.
Table 360: Input integer value converted to binary output signals
Measured supervised
value is:
below low-low
limit
between low‐
low and low
limit
between low
and high limit
between high-
high and high
limit
above high-
high limit
Output:
LOWLOW High
LOW High
NORMAL High
HIGH High
HIGHHIGH High
11.9 Limit counter L4UFCNT
GUID-22E141DB-38B3-462C-B031-73F7466DD135 v1
