PID-6829-INPUTSIGNALS v3
Table 403: GOOSEINTRCV Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of function
SRCINTOUT INTEGER 0 Source to integer output
PID-6829-OUTPUTSIGNALS v3
Table 404: GOOSEINTRCV Output signals
Name Type Description
INTOUT INTEGER Integer output
DATAVALID BOOLEAN Data valid for integer output
COMMVALID BOOLEAN Communication valid for integer output
TEST BOOLEAN Test output
14.4.7.5 Settings
PID-6829-SETTINGS v3
Table 405: GOOSEINTRCV Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
14.4.7.6 Operation principle
GUID-5BBDF772-3B3E-4F7C-ABE9-18CE3C1A2E2D v4
The DATAVALID output will be HIGH if the incoming message is with valid data.
The COMMVALID output will become LOW when the sending IED is under total
failure condition and the GOOSE transmission from the sending IED does not
happen.
The TEST output will go HIGH if the sending IED is in test mode.
Data Value Data Valid Comm Valid Test
Incoming data with q=Normal Updated 1 1 0
Incoming data with q=oldData Freeze 0 1 0
Incoming data with q=Invalid Freeze 0 1 0
Incoming data with q=test Freeze 0 1 1
Incoming data with q=test+oldData Freeze 0 1 1
Receiver in block Freeze 0 1 0
Receiver in block and communication
error
Freeze 0 0 0
Table continues on next page
1MRK 505 384-UEN A Section 14
Station communication
Breaker protection REQ650 2.2 IEC 531
Technical manual
