Name Type Description
BI7 BOOLEAN Binary input 7 value
BI8 BOOLEAN Binary input 8 value
BI9 BOOLEAN Binary input 9 value
BI10 BOOLEAN Binary input 10 value
BI11 BOOLEAN Binary input 11 value
BI12 BOOLEAN Binary input 12 value
BI13 BOOLEAN Binary input 13 value
BI14 BOOLEAN Binary input 14 value
BI15 BOOLEAN Binary input 15 value
BI16 BOOLEAN Binary input 16 value
OSCWRN BOOLEAN Oscillation warning
17.2.7.4 Settings
PID-3473-SETTINGS v2
Table 548: BIM Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - On Operation Off/On
DebounceTime 0.001 - 0.020 s 0.001 0.001 Debounce time for binary inputs
OscBlock 1 - 40 Hz 1 40 Oscillation block limit
OscRelease 1 - 30 Hz 1 30 Oscillation release limit
17.2.7.5 Monitored data
PID-3473-MONITOREDDATA v2
Table 549: BIM Monitored data
Name
Type Values (Range) Unit Description
STATUS BOOLEAN 0=Ok
1=Error
- Binary input module
status
1MRK 505 384-UEN A Section 17
IED hardware
Breaker protection REQ650 2.2 IEC 691
Technical manual
