4-4 Climate control
& Ventilator
! Center ventilators
Move the tab to adjust the flow direction.
! Side ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the side grille
open/close wheel upward.
To close it, turn the wheel downward.
! Rear ventilators
Move the tab or rotate it to adjust the flow
direction.
