4-12 Climate control
2. Unhook the strap.
3. Remove the glove box by detaching
the one clip on the side.
4. Remove the air filter cover by detach-
ing the five clips.
5. Unhook the air filter and draw it out.
6. Replace the air filter with a new one.
7. Install the air filter cover.
8. Install the glove box.
9. Attach the strap to the hook.
To Next Page
