Suffolk SS100 - Page 13

SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 13
SS REF No.
SUPPLIED
REQUIRED
SECTION 1 CHASSIS BUILD UP Page
2
DESCRIPTION
★ Special order
042
Front top ball joints x2
043
Front upper wishbone inner mounting shaft x2
044
Front chrome washers x8
045
Front upper caster shims x6
046
Front wheel bearing car set (early or late type)?
047
Front upright s/axle + washer, nut & cap
048
Front steering drop arms 1LH + 1RH
049
Front brake pipe support brackets x 2
050
Front hubs x 2
051
Front brake discs x 2
052
Front calipers x 2 + special mounting bolts & lock wire
053
Front brake pads x 2
054
Rear shocks + springs x 4
055
Rear shock mounting pins x 4 + spacers & washers + springs
056
Rear hubs fully built up x 2 (labour)
057
Rear hubs x 2
058
Rear hub carriers x 2
059
Rear oil seal tracks rear x 2 large + 2 small
060
Rear seals and taper bearings x 4ea + tubes x 2
061
Rear wheel bearing kits + shims x 2
062
Rear tie bar brackets x 2
063
Rear differential + top bolts + breather
Ratio:
064
Rear differential side mounts x 2 + tubes x 2 + bolts
065
Rear drive shafts shortened x 2
066
Rear lower arms shortened x 2
067
Rear discs x 2
068
Rear brake pads x 2
069
Rear calipers x 2 + mounting bolts
070
Rear handbrake calipers x 2 (inc. pads) + springs x 2
071
Rear universal joints drive shaft x 4
072
Rear needle rollers x 8 + sleeves x 4
073
Rear washers/seals/rings x 8
074
Rear wishbone pins x 2 inner + 2 outer
075
Rear driveshaft flanges x 2 inner + 2 outer
076
Rear driveshaft shims x 14
077
★ Build up whole rear end + (assy labour) includes 056 labour
All items 056-076
078
Nut and bolt kit. Labeled for build-up sections
079
Splined hubs, x 5. 3 x LH, 2 x RH
080
Spinners, x 5. 3 x LH, 2 x RH, chromed with SS logo
081
Brake drums, dummy, x 4.
082
Wheel nuts, x 20. Donor/ new. Machined
★ Delivery to: Date of Delivery:
Delivery Diesel or courier costs:
