Suffolk SS100 - Wiring of Rear Lamps

SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 93
Figure 24 – Wiring of rear lamps
It is optional which way around you mount your rear lamps i.e. red outside or inside. Suffolk
Sportscars suggest the way below as this means the tail lamp also known as the marker lamp is
towards the outer edge of the body marking the outer most position of the body.
