SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 7
threaded M14 fine (1.5mm pitch), and the bolts securing the front brake callipers and steering arms, which
are M12 fine (1.25mm pitch). Where metric threads are used on other components they are isometric (coarse
series).
SU carburettors use BSF and BA, while most of the fittings to the windscreen are 2BA.
It is recommended that stainless steel fastenings are used for fittings to the body and for those directly
exposed to dirt, salt etc. from the road. Stainless nuts and bolts in unified threads are difficult to obtain, but
metric are readily obtainable and are used for this reason wherever possible.
It is recommended that all non-stainle
ss fasteners are high tensile nickel-plated. Suffolk Sportscars can
supply all nuts, bolts and fasteners in a comprehensive boxed & labeled kit. Nut and bolt sizes are listed
within the kit for each operation in the build schedule. Owing to the diversity of component suppliers both
imperial and metric threads are used.
All Jaguar components (with very few exceptions) use unified (imperial) threads, mostly UNF, but UNC is
used for threads in aluminium alloy. Exceptions are steering racks on some later cars where the track rods
are threaded M14 fine (1.5mm pitch), and the bolts securing the front brake callipers and steering arms,
which are M12 fine (1.25mm pitch). Where metric threads are used on other components they are isometric
(coarse series).
SU carburetors use BSF and BA, while most of the fittings to the windscreen are 2BA.
It is recommended that stainless steel fastenings are used for fittings to the body and for those directly
exposed to dirt, salt etc. from the road. Stainless nuts and bolts in unified threads are difficult to obtain, but
metric are readily obtainable and are used for this reason wherever possible.
It is recommended that all non-stainless fasteners are high tensile nickel-plated.
2.3 Ordering of parts
Please photocopy the proforma of the customer order form (Appendix 7) and complete as required. Please
date and number your orders sequentially and send them to:
Roger Williams
Suffolk Sportscars Ltd
POBox 100
Woodbridge
Suffolk IP12 9BA
Please keep a copy of your orders for reference purposes.
Parts Delivery Disclaimer
We try to offer the best possible service at Suffolk
Sportscars and we are happy to deliver items to your
home or workplace. The driver will assess whether or not he can physically maneuver the items into place
and will only do so if items pass freely through the spaces provided.
Customers responsibility:
1. to ensure that the storage area is already prepared to receive the items prior to their arrival.
2. for the welfare of the goods as soon as they arrive on site.
3. for the welfare of the persons involved in lifting heavy / awkward items.
Once you have ordered your parts and you have a delivery date please make sure you have the space required
ready for delivery, in case of the body delivery please make sure there is sufficient space around the chassis
