Suffolk SS100 - Appendix 1: Electrical Systems

SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 72
Appendix 1: Electrical Systems
Wiring Loom Positions Key (Refer to Appendix 2 Fig 31)
A.Gearbox section
Green
Yellow/Blue
Overdrive inhibitor switch
Ignition supply
Switched feed out
Grey/red
Automatic gear selector switch
Ignition supply
Green
Green/brown
Reversing lamp switch
Ignition supply
Switched feed out
Yellow
Overdrive
Relay controlled feed
Black/White
Handbrake
Supply’s earth to warning lamp
B. Rear section
White/purple
Fuel pump feed
Relay controlled supply
Multi black
Eyelet – earth to chassis
Supply’s earth to rear lamps
Black
Green/black
Fuel sender
Earth feed
Feed to gauge
Black
Red/brown
Rear fog lamp
Earth feed
Switched live feed
Black
Green/purple
Red/white
Green/white
Right hand rear lamp
Earth feed
Stop lamp feed
Side light feed
Indicator lamp feed
Black
Green/brown
Reversing lamp
Earth feed
Switched live feed
Black
Green/purple
Red/black
Green/red
Left hand rear lamp
Earth feed
Stop lamp feed
Side light feed
Indicator lamp feed
C. Under bonnet section
Black eyelet
Black
Black/white
Low brake fluid level
Connect to chassis
} Connect to master
} cylinder cap
Green
Green/purple
Stop lamp switch
Ignition feed
Switched feed out
White/red
Starter solenoid
Feed from battery
Green
Spare switched ignition feed
Ignition live
White/green
Yellow/black
Black loop
Coil
Coil +
Coil –
Coil – to points in distributor
White/brown
Electric oil pressure gauge
Optional
Green/blue
Electric water temperature gauge
Optional
Thick brown
Brown/yellow
Alternator plug
Charging feed
Feed to warning lamp
D. Dash section
Brown (rear relays)
Main live supply
Connect to battery +
Blue
Flying lead to indicator stalk
Headlamp feed
Black eyelets (2)
Earth for relay box
Connect to chassis
Blue/red
Blue/white
Green/brown
Green/white
Green/red
Purple
Purple/black
Black
Indicator stalk
Dipped beam feed
Main beam feed
Indicator feed
Right indicator
Left indicator
Headlight flash feed
Horn (relay)
Earth for horn relay
Green
Black/white (2)
Low brake fluid & handbrake warning lamp
Ignition feed
Switched earth feed
Blue/white
Main beam warning lamp
Switched live feed
Green/white
Black
Right indicator warning lamp
Switched live feed
Earth feed
Green/red
Black
Left indicator warning lamp
Switched live feed
Earth feed
Thick brown (2)
White (2)+White/green
Red/yellow
Steering lock ignition key
Live feed – connect to brown
Ignition – connect to pink
Starter – connect to white
