SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 73
D.
Dash section (continued)
Black
Purple
Green/white
Green/red
Haz
ard lamp switch, MOT requirement if donor car
fitted with one otherwise optional
Earth feed
Live feed, connect to flasher
Fight indicator feed
Left indicator feed
Black
Green/yellow
Heater fan
Earth feed
Switched live feed
Black
Red/green
Blue/green
Wip
er motor
Earth feed
Slow speed feed
Fast speed feed
Black – multi eyelet
Main harness earth
Bolt to chassis hoop
Green
Grey/red
Automatic gearbox selector lamp
Fit fuse between wires to
Activate
Green
White/brown
Electric oil pressure gauge (optional)
Ignition live feed
Sender feed
Green
Green/blue
Electric water temperature gauge (optional)
Ignition live feed
Sender feed
Green
Brown/yellow
Ignition low charge warning lamp
Ignition live feed
Switch feed
Green
Green/yellow
Heater fan switch
Ignition live feed
Switch feed out
Black (8)
Red/white (8)
Gauge illumination
Earth
To gauge illumination lamps
Black
Red/white
Multi wires of each colour joined together
As junction for above, leave unconnected
Can be used for other illumination eg
cigar lighter
Thick brown (red tape)
2 x Thick brown (black
tape)
Ammeter, reverse connections if gauge backwards (ie
shows charging when discharging)
Ammeter feed
Ammeter out
Brown
Blue
Red
Sid
elight & headlamp switch
Live feed in
Headlamps out
Side & panel lights
Red/yellow
White/red
Starter button
Live from ignition key
To starter solenoid
Green
Red/green
Blue/green
Windscreen wiper switch.
Two speed options available
Ignition feed in
Slow speed feed
Fast speeed feed
Green (male)
Green (female)
Black (eyelet)
Voltage stabiliser for fuel gauge (and electrical
temperature gauge if fitted)
Ignition live out
Ignition live in
Earth
Green
Green/black
Fuel gauge
Ignition live
To earth via sender
Yellow/blue
Yellow/green
Overdrive switch
Feed from inhibitor switch
Feed to relat
Red/orange
Red/brown
Rear fog lamp switch
Live feed
Switched live to lamp
Thick brown
Blue/pink (2)
Front spot lamps (optional)
Connect to blue/pink pair via switch or
relay controlled by main beam
Black
Green
Yellow/black
Tac
hometer (Note If using electronic ignition connect
yellow/black to white/black on tachometer)
Connect to black on tachometer
Connect to green on tachometer
Connect to red/blue on tachometer
E. Headlamps & Horns
Blue/red
Blue/white
Red/white
Green/white
Purple/yellow
Rig
ht hand lamps & Horn
Dip beam
Main beam
Side lamp
Indicator lamp
Horn
Blue/pink
Right spot lamp
Feed from dash
Orange
Orange/black
Black
Black eyelet
Coo
ling fan
Live feed from relay
Thermostatic switch control from relay+
Earth
Connect to chassis
Blue/pink
Left spot lamp
Feed from dash
Blue/red
Red/white
Red/black
Green/red
Purple/yellow
Lef
t hand lamps & horm
Dip beam
Main beam
Side lamp
Indicator lamp
Horn
