Suffolk SS100 - Electrical Instruments and Automatic Gearbox Illumination; Low Charge Warning; Main Wiring Earth; Wiper Motor

SS100 Build Manual (Export Edition) Rev 10 November 2013
Page 54
Changeover switch contact
Wire
Power
Common input
Green/Yellow
+12v dashboard switched feed
Output one
Orange (slow fan speed)
+12v switch feed 1 to fan
Output two
Red (fast fan speed)
+12v switch feed 2 to fan
9.1.9 Wiper motor
Along side the heater fan wires are the wiper motor wires these can be connected as follows:
Wiper motor wires
Loom Wires
Power
Blue/Green
Green
+12v Ignition feed
Red/Green (Slow speed)
Red/Green
-12v Dash switched feed 1
Yellow/Green (fast speed)
Blue/Green
-12v Dash switched feed 2
9.1.10 Main wiring earth
Next wires exiting the loom will be the thick multi black earth eyelet, which should be bolted to the left hand
bolt in the roll hoop that holds the wiper “Z” bracket, clean this area to make sure of a good earth connection.
This should already be connected from section 3 above to help position the wiring loom.
9.1.11 Electrical instruments and Automatic gearbox illumination
Along with the earth eyelet are six wires provided for electric gauges and Automatic gearbox illumination.
Some gauges may have + marked on the gauge others can be connected either way around.
Oil pressure gauge
Loom Wires
Power
1
st
Terminal
Green
+12v ignition from voltage regulator
2
nd
Terminal
White/Brown
-12v variable from engine switch
Water temperature gauge
1
st
Terminal
Green
+12v ignition from voltage regulator
2
nd
Terminal
Green/Blue
-12v variable from engine switch
Automatic gearbox illumination
Join these two wires together
through a fuse
Green
+12v ignition feed input
Grey/Red
+12v feed to illumination
9.1.12 Low charge warning
The remaining wires should follow the wiper drive track and turn back across the dashboard from left to
right, all the instruments and switches can be wired and fitted at the same time or you can fit all instruments
and switches and wire from behind. The first two cables are for low charge warning lamp these will need
female spades crimped or soldered on.
Low charge warning lamp
(Red)
Loom wires
Power
1
st
Terminal
Green
+12v ignition control feed
2
nd
Terminal
Brown/yellow
-12v from Alternator +12v when engine running
9.1.13 Heater fan switch
The next two are for the heater fan switch. The heater fan switch has screw terminals, as with all this type of
screw terminal connection the wires need baring back before inserting behind screw (the connection will be
stronger and longer lasting if you tin the wire ends with solder before inserting in switch).
Heater fan switch
Loom wires
Power
1
st
Terminal
Green
+12v ignition control feed
2
nd
Terminal
Green/Yellow
+12v feed to fan
9.1.14 Water temperature gauge
Next
fit the water temperature gauge, if using electric gauge extend wires to reach wires in section 12
above, if using Suffolk Sportscars supplied mechanical gauge the capillary tube needs to be fed through the
dashboard
