9.1.18 Dashboard ignition key
The dashboard ignition key is next, this usually has two pairs of terminals on it, we need to use one of each.
The spare terminals could be used to power other accessories if required from either a Permanent or Ignition
supply. The Ignition key supplies the steering ignition key and acts as a master key switch.
The terminals can be connected either way around.
Switch
positions
Loom wires
Power
1
st
Terminal
Brown
+12v live from ammeter
1
st
Terminal
+12v Can be used for permanent fed accessory, use fuse.
2
nd
Terminal
Brown (With Blue tape)
+12v feed to steering column key
2
nd
Terminal
+12v Can be used for key controlled accessory, use fuse.
9.1.19 Starter push button
The starter push button sits central at the bottom the dashboard and usually needs to be fitted before
connecting as the switch wont fit through the dashboard once it has been wired.
Starter push button
Loom wires
Power
1
st
Terminal
Red/Yellow
+12v input from steering column key
2
nd
Terminal
White/Red
+12v output to starter motor
9.1.20 Fuel gauge
Next fit the Fuel gauge. This needs to be wired through the voltage regulator (the small metal box with two
pairs of terminals) as fluctuating voltage will cause an unstable fuel reading. The fuel gauge can be wired
either way around.
Voltage regulator
Loom wires
Power
Terminal B
Green, Female spade
+12v ignition feed
Terminal I
Green, Male spade
+12v to gauge
Regulator case
Black (this cable will be taped with wires
below)
-12v chassis earth
Fuel gauge
Loom wires
Power
1
st
Terminal
Green
+12v from voltage regulator
2
nd
Terminal
Green/Black
-12v from fuel tank sender
9.1.21 Windscreen wiper switch
Under the fuel gauge is the windscreen wiper switch, like the heater fan switch only single speed switches
are available to match SS100 pull switches, options are:
1) Choose which speed suits you best and only connect that wire.
2) Use a two-speed dash switch, at present no new switches are available to match the SS100 pull
switches.
3) Wire up a two-position changeover switch behind the dashboard, wiring details below, this way the
dash pull switch will turn on the wipers and the speed set by the extra hidden switch.
Wiper switch wires
Loom wires
Power
1
st
Terminal
Black
-12v Input
2
nd
Terminal
Red/Green (Slow)
-12v output to wiper motor
Or Blue/Green (fast)
Or to switch below
Changeover switch contact
Wire
Power
Common input
Output from above switch
-12v
Output one
Red/Green (slow)
-12v to wiper motor
Output two
Blue/Green (fast)
-12v to wiper motor
