4:
The fiber is cleaved.
4-1: Open the top clamp lever.
20
1. Do not re-clean the fiber after cleaving.
2. To avoid damaging or contaminating the delicate fiber ends, insert
each fiber immediately after preparation.
3. Glass-fiber fragments are extremely sharp. Handle with care.
4-2: Lift the fiber holder.
4-3: Lift the off-cut and dispose of it
properly.
*Be careful not to touch the off-cut
against the fiber end face.
4-4: Place the fiber holder into the
TYPE-66.
Off-cut
4-5: Cleave the other fiber in the
same way.
Caution
To Next Page
