[TYPE-66M12 specifications]
Material Silica glass
55
Profile type
SMF (ITU-T G.652), MMF (ITU-T G.651)
DSF (ITU-T G.653), NZDSF (ITU-T G.655)
Optical fiber
requirement
Fiber diameter 125 μm
Fiber coating diameter Single fiber 0.25mm, 0.5mm, 0.9mm
Ribbon fiber 0.28~0.4mm
Cleave length 10mm
Fiber count 1,2,4,5,6,8,10,12
Size (main body) *1 150W × 150D × 150H (mm)
Weight Approx. 2.7 kg (with PS-66)
Approx. 2.9 kg (with BU-66S)
Size and
weight
Monitor 5.6” TFT color monitor
:0.05dB Typical splice loss *2 SMF
MMF
DSF
NZDSF
:0.03dB
:0.08dB
:0.08dB
Typical splice cycle time *2 Approx. 15 seconds (Single fiber)
Approx. 18 seconds (4-fiber ribbon)
Approx. 20 seconds (8-fiber ribbon)
Approx. 20 seconds (12-fiber ribbon)
Typical heating cycle time *3 FPS-1 (Single fiber) Approx. 55 seconds
FPS-5 (8-fiber ribbon) Approx. 45 seconds
FPS-6 (12-fiber ribbon) Approx. 75 seconds
Splice & heat cycles per fully
charged battery *4
Approx. 80 (BU-66S)
Approx. 160 (BU-66L)
Loss Estimation Provided
Splice data storage 2,000 splices
Functions
Tension test *5 1.96N (200gf)
Heat shrink oven 2 built-in heat shrink ovens
Automatic arc test Provided
Provided V-groove white LED illumination
Interface USB1.1 type-B
Splice programs Max. 60 Programs
Heating programs Max. 20
AC operation With PS-66
Input: AC 100/120/220/240V +/-10%
50/60Hz +/-5%
Voltage Dips: within 30% 0.5periods,
within 60% 50periods
Fast transients/burst: within 1kV 5kHz 1minuite
Power supply
DC operation With PS-66 and car battery cable
Input: DC 12V (10.5 – 15V)
Battery operation With BU-66S or BU-66L
Nominal capacity BU-66S: 4500mAh
BU-66L: 9000mAh
Nominal voltage: 13.2V
DC output 12V For Sumitomo’s hot jacket remover
Operation temperature *6 -10 °C ~ +50 °C
Storage temperature *6 *7 -40 °C ~ +80 °C
Altitude Max. 3,660m
Environmental
conditions
Windproof Max. 15m/s
