21
2: Place the other fiber holder in the
same way.
4: Close the hood.
5: Start an arc test, and then the splicing process.
1: Place the fiber holder onto the holder stage, fitting the pin of the fiber
holder stage into the hole of the fiber holder.
Do not touch the fiber end face
against any surface.
Inserting fibers into the splice
0: Open the hood.
3: Ensure that the fibers are resting
in the V-groove.
The position of fiber placement is
different depending on the number of
fibers.
Place the fibers looking at the
illuminated fiber guide light.
