Sumitomo TYPE-66M12 - Starting Automatic Splice

25
Starting the automatic splice
Inspection of fiber end face & dust
Arc is generated.
Fiber inspection after splice
Estimated losses are displayed.
Ready [SM:12c-40mm 12c]
Y
Prefusion check
Y
Arc 0000
Y
Postfusion check 0000
Y
Y X
(Arc Count is displayed on the screen.)
Y
X
Open Hood Ave:0.01dB
3
5
1
2
4
6
7
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
9
8
11
10
12
“Open Hood” is displayed.
Proof test is performed.
After proof test, “Complete” is displayed.
Press the (SET) key.
Y
Y
Complete
Remove fiber
Proof
3
5
1
2
4
6
7
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
9
8
11
10
12
0.01
Estimation Loss
Ave:0.01dB
