Sumitomo TYPE-66M12 - Tripod Mounting Options

49
The TYPE-66 has screw holes for M8 screw and 1/4-20UNC screw. In a high location,
fix the splicer to a tripod to prevent it from dropping.
Screw hole for
M8 screw
Screw hole for
1/4-20UNC screw
In a high location, fix the TYPE-66 to a tripod with the M8 screw or
1/4-20UNC screw on the bottom of the splicer to prevent the splicer from
dropping.
Tripod fixing screws
Caution
