Chapter 2 Installing the Server Into a 19-Inch Cabinet 23
2. Attach the rear brackets to the rear rails of the cabinet using four 10-32 screws.
Align the lower hole of each rear bracket with the rail hole you marked in
“Determine the Vertical Position of the Server in the Cabinet” on page 20.
Secure the brackets using one 10-32 screw in each lower hole. Finger-tighten the
screws.
Align the upper hole of each rear bracket with the coinciding hole in the cabinet rail.
Secure the brackets to the rails using one 10-32 screw in each upper hole. Finger-
tighten the screws.
Do not tighten the screws completely until all the screws are in place and the tray
assembly is level.
3. Make sure the tray assembly is level.
Use a level to ensure the tray assembly is level front-to-back and left-to-right.
Adjust as necessary.
4. Once the tray assembly is level, completely tighten all of the bracket screws.
Tighten the eight 10-32 screws that secure the front and rear brackets to the vertical
cabinet rails.
5. Slide the tray assembly in and out of the cabinet to be sure the slides operate
smoothly.
Installing the Server Into the Tray
Assembly
1. Be sure the cabinet is stabilized so that the cabinet cannot move or tip forward
when the tray is extended and the server is placed on the tray.
If there are feet beneath the cabinet to prevent it from rolling, be sure the feet are
fully extended downward to the floor.
Stabilize the cabinet using the stabilizing mechanisms provided with the cabinet.
See the instructions provided with the cabinet.
Caution – Before you slide the tray out, be sure the cabinet is stabilized so that it
cannot move or tip forward. See the cabinet documentation for information about
stabilizing the cabinet.
!
