98 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
following table.
Data Operation Data Operation
00H Invalid instrument 10H To set running freq. of slave
01H Start with FWD 11H Start with FWD and setting freq.
02H Start with REV 12H Start with REV and setting freq.
03H Stop 13H Stop with Start setting freq.
04H
Slave will FWD running
when jog
14H
Slave will FWD running with setting
freq. when jog
05H
Slave will REV running
when jog
15H
Slave will REV running with setting freq.
when jog
06H Jog running is stop 16H Slave will JOG running with setting freq.
… … … …
20H Slave will fault reset 30H Reserved
21H Slave will emergency stop 31H Reserved
2.4.5 Slave responding
Slave responding exists in all messages and is shown as following table.
Data Definition Data Definition
0
Slave receive data and works well
1
Data received form master is beyond the
permission range
2
When slave is running, data can’t be
modified
3
If modify the data, please input password
4 To try read and write parameter 5 Reserved
6 Appointed code or addr. Is invalid 7 It exist invalid ASC code in messageⅡ
8
Type of order or operation order is
invalid
9～F
Reserved
Its frame format is shown as following.
0 1 2 3 4 5 6 7 8 9 10
Slave
responding
Slave
address
Slave
address
Slave
responding
0 0
Check
Sum
Check
Sum
Check
Sum
Check
sum
Tail
Definition
Header
Slave address Order/responding area Check area 0DH
2.4.6 State feedback
Slave gives a running state about slave to master, and state feedback exists in all
messages. It is shown as following table.
When user need not send operation order, please send invalid order 00H.
¾ When data of slave responding is 6, 7 or 8, length of responding frame is
11 b
y
tes.
