64 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
The first part of LED：
0：Invalid 1： Valid
When restart after setting power off is invalid, the inverter will clear automatically all
running command and run according to new command after power on.
When restart after setting power off is valid, the inverter will save all running
command and run according to the save command after power on.
Please make sure that other equipments in system are ready before using function
of restart after power down.
The second part of LED：
Applied motor is still running when user select restarting. Here, you have to select
function of detected speed and restart.
The third and fourth part of LED: reserved.
6.6 Multi-speed running parameter unit
Parameter F5.0 is multi-speed running mode. It is used for setting basic
characteristics of multi-speed running.
The first part of LED(form right to left)：Simple PLC selection
F4.28 Reserved
F5.0 Multi-speed running mode Setting range：0000 ~ 1252
F5.1 Multi-speed frequency 1 Setting range：0.0 ~ the upper limit freq.
F5.2 Multi-speed frequency 2 Setting range：0.0 ~ the upper limit freq.
F5.3 Multi-speed frequency 3 Setting range：0.0 ~ the upper limit freq.
F5.4 Multi-speed frequency 4 Setting range：0.0 ~ the upper limit freq.
F5.5 Multi-speed frequency 5 Setting range：0.0 ~ the upper limit freq.
F5.6 Multi-speed frequency 6 Setting range：0.0 ~ the upper limit freq.
F5.7 Multi-speed frequency 7 Setting range：0.0 ~ the upper limit freq.
F5.8 Multi-speed frequency 8 Setting range：0.0 ~ the upper limit freq.
F5.9 Running time of Multi-speed1 Setting range：0.0 ~ 6000s
F5.10 Running time of Multi-speed2 Setting range：0.0 ~ 6000s
F5.11 Running time of Multi-speed3 Setting range：0.0 ~ 6000s
F5.12 Running time of Multi-speed4 Setting range：0.0 ~ 6000s
F5.13 Running time of Multi-speed5 Setting range：0.0 ~ 6000s
F5.14 Running time of Multi-speed6 Setting range：0.0 ~ 6000s
F5.16 Running time of Multi-speed8 Setting range：0.0 ~ 6000s
F5.17 Running direction of PLC multi-speed Setting range：0000 ~ 1111
F5.18 Running direction of PLC multi-speed Setting range：0000 ~ 1111
F4.26 Restart after power down setting Setting range：0000 ~ 0011
F4.27 waiting time of restart after power down Setting range：0.0 ~ 10.0s
