58 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
Refer to the explanation about parameter F6.3.
13Designated value of counter arrives
Refer to the explanation about parameter F6.4.
14Reserved
15Reserved
16Inverter faults
When inverter is running with faults, it will output available signal (low level).
17Restrictions on wobble freq. of the upper and lower limit freq.
When parameters setting about wobble freq. result in that running freq. is beyond
the upper and lower limit freq., this port will output available signal (lower lever).
Generally, this port output high resistance.
18Reserved
If output freq. of inverter is within setting value that is set in F3.9, selected terminal
will output valid signal. Shown as fig.6-13.
The parameter is used for setting the frequency detection level. When output
frequency is higher than the setting value of FDT, after the setting delay time,
terminals will output the valid signal, shown as fig.6-14.
If output freq. beyond the setting value set by parameter F3.9, after the setting
delay time set by parameter F3.10, terminals output valid signal, shown as fig.6-15.
6.5
Auxiliary running parameter unit
Those parameters are used for defining characteristics with relation to start mode,
shown as fig6-16.
The explanation of F4.0 is shown as follows:
0 Routine mode
It is fit for mostly lodes, which have not special demand.
1Detect speed and restart
It is fit for fault reset and restart occasion, or, power off and restart occasion.
Inverter will judge automatically running speed and direction of motor. Motor, which
F3.11 Reserved
F3. 6 Frequency reach the checkout amplitude Setting range0.0 ~ 20.00Hz
F3.7 FDT setting Setting range0.0 ~ upper limit freq.
F3.8 FDT output delay time Setting range0.0 ~ 200.0 s
F3.9 Overload alarm level Setting range50 ~ 200%
F3.10 Overload alarm delay time Setting range0.0 ~ 20.0s
F4.0 Start mode Setting range01
F4.1 Start frequency Setting range0.010.00Hz
F4.2 Start fre
q
uenc
y
duration Settin
g
ran
g
e0.020.0s
