Sunfar C300 Series User Manual

SUNFAR C300 99
C300 series of non-sensor current vector-control inverter manual
Data Operation Data Operation
00H
DC voltage of slave is not
ready
10H Reserved
01H Slave is FWD running 11H Accelerating with FWD
02H Slave is REV running 12H Accelerating with REV
03H Slave is stop 13H Abruptly stop and restart
04H
Slave will FWD running when
jog
14H Decelerating with FED
05H
Slave will REV running when
jog
15H Decelerating with REV
06H Reserved 16H Slave is in DC braking state.
… … … …
20H Slave is in fault state 21H Slave is emergency
2.4.7 Check sum
The sum of ASC or hex form slave address to setting data (running data) is check Ⅱ
sum.
2.4.8 Frame Tail
0DH is hex, namely ASC of CR is 0DH. Ⅱ
3. Description about frame format
(1) Order is read state and information about slavesⅠ
0 1 2 3 4 5 6 7 8 9 10 11 12 13
Master
Sending
Header
Slave
addr.
Slave
addr.
0
Operation
order
Operation
order
Data
Type
00
Check
Sum
Check
Sum
Check
Sum
Check
Sum
Tail
When slave occurs fault (data of state feedback is 20H), the seventh and eighth
of feedback rata frame is fault code.
When header, tail and check sum in message occur fault form master, slave may
bt di
