Sungrow AC011E-01 User Manual

3
Electrical Connection Ports
figure 1-1 Ports
table 1-1 Label Explanation
Position Description
A Charging cable output (pre-assembled with charging cable)
B RS485 communication interface (SHRTconnection)
C AC input (AC connection)
User Manual 1 Product Overview

Sungrow AC011E-01 Specifications

General

Model	AC011E-01
Category	Battery Charger
Output Power	11 kW
Frequency	50/60 Hz
Operating Temperature	-25°C to +60°C
Protection	Overvoltage, Overcurrent, Short Circuit, Over Temperature
Communication	RS485/CAN
