Appendix
7.1 Technical Data
Specification
AC011E-01
AC Input and Output
Max. charge power
11 kW
Nominal voltage
400 V
Nominal grid frequency
50/60 Hz
Max. current
16 A three-phase
Charge connector Plug Type 2
Cable cross-section 5*2.5 mm
2
Cable Length
7 m
protection
Residual current detection 6mA DC
Over/Under voltage protection
Yes
Over load protection
Yes
Over temperature protection
Yes
Surge protection
II
Overvoltage category III (grid)/II (car)
General Data
Dimensions (W*H*D)
310 mm * 205 mm * 92 mm
Weight 3.8 kg
Mounting method Wall-Mounting/Pole-Mounting (optional)
Impact resistance
IK08
Degree of protection
IP65
Operating ambient temperature
range
-30 to 50 °C
Allowable relative humidity range
(non-condensing)
5 % to 95 %
Cooling method
Natural convection
Max. operating altitude
2000 m
