Sungrow AC011E-01 User Manual

47
Charger Status LED Signals
CP failure
The red LED blinks for 5 times (on for 0.5 s, off for 0.5 s) and then
off for 3 s
Overcurrent
The red LED blinks for 6 times (on for 0.5 s, off for 0.5 s) and then
off for 3 s
Stuck replay
The red LED blinks for 7 times (on for 0.5 s, off for 0.5 s) and then
off for 3 s
Abnormal leakage
current loop
The red LED blinks for 8 times (on for 0.5 s, off for 0.5 s) and then
off for 3 s
Input terminal
overtemperature
The red LED blinks for 9 times (on for 0.5 s, off for 0.5 s) and then
off for 3 s
Relay
overtemperature
The red LED blinks for 10 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
Undervoltage
The red LED blinks for 11 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
Overvoltage
The red LED blinks for 12 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
Overfrequency
The red LED blinks for 13 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
Underfrequency
The red LED blinks for 14 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
CT error in the smart
meter
The red LED blinks for 15 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
Communication error
with the smart meter
The red LED blinks for 16 times (on for 0.5 s, off for 0.5 s) and
then off for 3 s
If the above faults cannot be removed, contact customer service.
User Manual 6 Troubleshooting

Sungrow AC011E-01 Specifications

General

Model	AC011E-01
Category	Battery Charger
Output Power	11 kW
Frequency	50/60 Hz
Operating Temperature	-25°C to +60°C
Protection	Overvoltage, Overcurrent, Short Circuit, Over Temperature
Communication	RS485/CAN
