4 Unpacking and Storage User Manual
16
型号 Model
序列号 S/N
ENERGY STORAGE CONVERTER
Lithium or Lead-acid Battery
DC 1000 V
DC 96.6 A
AC 3~ 600 V
540 to 660 Vac(IEC)
最大输入电流 Max. Input Current
功率因数 Output Power Factor
工作电压范围 Operating Voltage Range
交流侧标称电压 Nominal Output Voltage
50/60 Hz
交流侧标称频率 Nominal Output Frequency
工作频率范围 Operating Frequency Range
最大输入电压 Max. Input Voltage
DC 1500 V
82.5 kW@45℃
YES
非隔离型逆变器 Non-isolated Inverter
SUNGROW POWER SUPPLY CO.,LTD.
www.sungrowpower.com
中国制造 Made In China
工作温度范围 Ambient Temperature
交流侧最大输出功率 Max. Continuous Output Power
蓄电池类型Storage Battery Type
AC 79.3 A
交流侧最大输出电流 Max. Continuous Output Current
Stand-alone or Grid Support Utility Interactive Inverter
防护等级 Enclosure
TYPE 4X/IP65
Contains Bluetooth ID:FCC(WAP2001)/IC(7922A-2001)
直流输入DC-Input
交流输出AC-Output
1.0 Leading … 1.0 Lagging
安全等级 Safety Class
Ⅰ
过压等级 Overvoltage Category(IEC)
Ⅲ【AC】,Ⅱ【DC】
额定输入电压 Rated Input Voltage
DC 870~1500 V
储能变流器
-25℃...+60℃
阳 光 电 源 股 份 有 限 公 司
528 to 660 Vac(NA)
工作电压范围 Operating Voltage Range
75 kW@50℃
SC75HV
47 to 52 Hz(IEC)
57 to 62 Hz(NA)
1
2
3
4
Fig. 4-1 Nameplate of PCS
*Image shown here is for reference only. Actual product you receive may differ.
Item
Description
1
SUNGROW logo and product type
2
Technical data of PCS
3
Warning signs of PCS.
4
Company name, website and origin
Tab. 4-1 Description of Icons on the Nameplate
Icon
Description
Don’t dispose of the PCS with the household waste.
5min
This symbol indicates that you should wait at least 5 minutes
after disconnecting the PCS from the utility grid and from the
DC input before touching any inner live parts.
!
The installation and service of the PCS unit can only be
performed by qualified personnel.
Hot surface! In order to reduce the risk of burns, do not touch
the hot surface when the device is running.
Refer to the corresponding instructions.
Don’t dispose of the PCS with the household waste.
