6 Electrical Connection
Once the PCS is secured to the installation site, it can be connected to the
energy storage system.
All electrical connections must comply with local regulations and related
electrical rules.
Improper cable connection may lead to a fatal injury or permanent
damage to the device.
Cable connections should only be done by qualified professional
personnel.
Always keep in mind that the PCS is AC and DC redundancy power
supplied. Electrical operators must wear proper personal protective
equipment: helmet, insulated footwear and glove, etc.
6.1 Terminals Description
All electrical terminals and cable openings of the PCS are located at the
connection cabinet as following figure.
2
1
3
5
6
8
7
4
