49
Fig. 8-8 Alarm records
Click " " to select a time segment and view corresponding
records.
The PCS can record up to 100 latest entries.
Select one of the records in the list and click the record, to view the detailed
fault info as shown in following figure.
Fig. 8-9 Detailed fault alarm info
8.7.2 Charge and Discharge Records
User can view various energy records: power curve, daily / monthly / annual
charge and discharge curve.
