Sungrow SG50CX User Manual

109
Parameters
SG30CX SG33CX
AC connection type
OT or DT terminal (Max.70 mm
2
)
Grid Support
Q at night function, LVRT, HVRT, active & reactive power con-
trol and power ramp rate control
Note(1): The inverter enters the standby state when the input voltage ranges between 1,000
V and 1,100 V. If the maximum DC voltage in the system can exceed 1000 V, the MC4 con-
nectors included in the scope of delivery must not be used. In this case MC4 Evo2 connec-
tors must be used.
Note(2):
• The voltage difference between MPPTs should be less than 80 V.
• The voltage of the configured string should be higher than the lower limit of the rated
MPPT voltage.
Parameters
SG40CX SG50CX
Input (DC)
Max. PV input voltage
1100 V
(3)
Min. PV input voltage /
Start-up input voltage
200 V / 250 V
Nominal PV input voltage 585 V
MPP voltage range 200 V ~ 1000 V
MPP voltage range for
rated power
550 V ~ 850 V
(4)
No. of independent MPP
inputs
4 5
No. of PV strings per
MPPT
2
Max. PV input current
4 X 26 A 5 X 26 A
Max. DC short-circuit
current
4 X 40 A 5 X 40A
Output (AC)
AC output power
40 kVA @ 45℃, 400 Vac / 44
kVA @ 40℃, 400 Vac 40 kVA
@ 50℃, 415 Vac / 44 kVA @
45℃, 415 Vac
50 kVA @ 45℃, 400 Vac / 55
kVA @ 40℃, 400 Vac 50
kVA @ 50℃, 415 Vac / 55
kVA @ 45℃,415 Vac
Max. AC output current
66.9 A 83.6 A
Nominal AC voltage 3 / N / PE，230 / 400 V
AC voltage range
312 ~ 528 V
Nominal grid frequency /
Grid frequency range
50 Hz / 45 ~ 55 Hz, 60 Hz / 55 ~ 65 Hz
User Manual 10 Appendix

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
