89
Step 4 Select the device model before downloading the firmware. Tap the device name in the device
list to enter the firmware upgrade package detail interface, and tap
behind the firmware
upgrade package to download it.
Step 5 Return to the Firmware Download interface, tap in the upper right corner of the interface
to view the downloaded firmware upgrade package.
Step 6 Login the App via local access. Refer to
"7.4 Login".
Step 7 Tap More on the App home screen and then tap Firmware Update.
Step 8 Tap the upgrade package file, a prompt box will pop up asking whether to upgrade the firm-
ware with the file, tap CONFIRM to perform the firmware upgrade.
Step 9 Wait for the file to be uploaded. When the upgrade is finished, a message is displayed indi-
cating that the upgrade is completed. Tap Complete to end the upgrade.
- - End
7.8.6 Grounding Detection
Contact your distributor to obtain the advanced account and corresponding pass-
word before setting the earth detection parameters. If the distributor is unable to
provide the required information, contact SUNGROW.
Unauthorized personnel are not allowed to log in with this account. Otherwise,
SUNGROW shall not be held liable for any damages caused.
Tap More→Settings→Operation Parameters→Grounding Detection to enter the corre-
sponding screen.
User Manual 7 iSolarCloud App

Table of Contents

Other manuals for Sungrow SG50CX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sungrow SG50CX and is the answer not in the manual?

Sungrow SG50CX Specifications

General IconGeneral
Max. DC Voltage1100 V
MPPT Voltage Range200 V - 1000 V
Max. Input Current per MPPT26 A
Number of MPPTs4
Rated AC Output Power50 kW
Max. AC Output Current76 A
Frequency50 Hz / 60 Hz
Efficiency98.6%
Start Voltage200 V
Number of DC Inputs per MPPT2
Max. AC Apparent Power55 kVA
AC Voltage Range310 V - 480 V
Power Factor at Rated Power1
Adjustable Power Factor Range0.8 leading - 0.8 lagging
THDi< 3%
DC SwitchYes
AC Surge ProtectionType II
DC Surge ProtectionType II
Protection ClassI
Cooling MethodSmart forced air cooling
Protection DegreeIP66
Protection LevelIP66
Operating Temperature Range-25°C to +60°C
Humidity0-100%
AC Output Voltage3 / N / PE, 220 V / 380 V, 230 V / 400 V
