Sungrow SG50CX User Manual

68
7
iSolarCloud App
7.1 Brief Introduction
The iSolarCloud App can establish communication connection to the inverter via the Blue-
tooth, thereby achieving near-end maintenance on the inverter. Users can use the App to
view basic information, alarms, and events, set parameters, or download logs, etc.
*In case the communication module Eye, WiFi or WiNet-S is available, the iSolarCloud App
can also establish communication connection to the inverter via the mobile data or WiFi,
thereby achieving remote maintenance on the inverter.
• This manual describes only how to achieve near-end maintenance via the
Bluetooth connection. For remote maintenance through the Eye, WiFi or
WiNet-S, refer to the related manuals in the delivery scope.
• Screenshots in this manual are based on the Android system V2.1.6 , and the
actual interfaces may differ.
7.2 Installing App
Method 1
Download and install the App through the following application stores:
• MyApp (Android, mainland China users)
• Google Play (Android, users other than mainland China ones)
• App Store (iOS)
Method 2
Scan the following QR code to download and install the App according to the prompt
information.
The App icon appears on the home screen after installation.

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
