11
figure 2-3 Product Dimensions(in mm)
*The image shown here is for reference only. The actual product you receive may differ.
Type Dimensions (W*H*D) Weight
SG30CX
702×595×310 mm
50 kg
SG30CX-NI
SG33CX
SG40CX
782×645×310 mm
58 kg
SG50CX
62 kg
SG50CX-NI
62 kg
2.3 Symbols on Product
Symbol Explanation
Do not dispose of the inverter together with household waste.
TÜV mark of conformity.
CE mark of conformity.
EU/EEA Importer.
RoHS labeling
The product complies with the requirements of the applicable EU
directives.
Regulatory compliance mark.
The inverter does not have a transformer.
User Manual 2 Product Description

Table of Contents

Other manuals for Sungrow SG50CX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sungrow SG50CX and is the answer not in the manual?

Sungrow SG50CX Specifications

General IconGeneral
Max. DC Voltage1100 V
MPPT Voltage Range200 V - 1000 V
Max. Input Current per MPPT26 A
Number of MPPTs4
Rated AC Output Power50 kW
Max. AC Output Current76 A
Frequency50 Hz / 60 Hz
Efficiency98.6%
Start Voltage200 V
Number of DC Inputs per MPPT2
Max. AC Apparent Power55 kVA
AC Voltage Range310 V - 480 V
Power Factor at Rated Power1
Adjustable Power Factor Range0.8 leading - 0.8 lagging
THDi< 3%
DC SwitchYes
AC Surge ProtectionType II
DC Surge ProtectionType II
Protection ClassI
Cooling MethodSmart forced air cooling
Protection DegreeIP66
Protection LevelIP66
Operating Temperature Range-25°C to +60°C
Humidity0-100%
AC Output Voltage3 / N / PE, 220 V / 380 V, 230 V / 400 V
