Sungrow SG50CX User Manual

80
Parameter
Description
Monthly yield
histogram
Shows the power output every month in a year.
Annual yield
histogram
Shows the power output every year.
Tap the time bar on the top of the interface to select a time segment and view the corre-
sponding power curve.
Swipe left to check the power yields histogram.
Event Record
Tap Event Record to view event record list.
Click
to select a time segment and view corresponding records.
The inverter can record up to 400 latest entries.
7.8 More
Tap More on the navigation bar to enter the corresponding interface, as shown in the follow-
ing figure.
figure 7-11 More
7.8.1 System Parameters
Tap “Settings→System Parameters” to enter the corresponding interface, as shown in the
following figure.
7 iSolarCloud App User Manual

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
