65
Step 7 Pull the cable gently to make sure it is secured, tighten the swivel nut clockwise.
- - End
5.13 Communication Module Connection (optional)
Connect the communication module produced by SUNGROW to the communication acces-
sory port. After successful connection, information such as power generation and running
state of the inverter can be viewed via the App on the phone.
*The image shown here is for reference only. The actual product you receive may differ.
Once the communication module is in use, do not connect the inverter to a 3rd
party data logger at the same time via RS485.
For details on module installation and configuration, refer to the manual delivered
together with the module.
User Manual 5 Electrical Connection

Table of Contents

Other manuals for Sungrow SG50CX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sungrow SG50CX and is the answer not in the manual?

Sungrow SG50CX Specifications

General IconGeneral
Max. DC Voltage1100 V
MPPT Voltage Range200 V - 1000 V
Max. Input Current per MPPT26 A
Number of MPPTs4
Rated AC Output Power50 kW
Max. AC Output Current76 A
Frequency50 Hz / 60 Hz
Efficiency98.6%
Start Voltage200 V
Number of DC Inputs per MPPT2
Max. AC Apparent Power55 kVA
AC Voltage Range310 V - 480 V
Power Factor at Rated Power1
Adjustable Power Factor Range0.8 leading - 0.8 lagging
THDi< 3%
DC SwitchYes
AC Surge ProtectionType II
DC Surge ProtectionType II
Protection ClassI
Cooling MethodSmart forced air cooling
Protection DegreeIP66
Protection LevelIP66
Operating Temperature Range-25°C to +60°C
Humidity0-100%
AC Output Voltage3 / N / PE, 220 V / 380 V, 230 V / 400 V
