Sungrow SG50CX User Manual

78
Classifica-
tion
Parameter
Description
Phase C Current
7.7 View Records
Tap Records on the navigation bar to enter the interface showing event records, as shown
in the following figure.
figure 7-7 Records
Fault Alarm Record
Tap Fault Alarm Record to enter the interface, as shown in the following figure.
figure 7-8 Fault Alarm Record
Tap to select a time segment and view corresponding records.
The inverter can record up to 400 latest entries.
Select one of the records in the list and tap the record to view the detailed fault information
as shown in following figure.
7 iSolarCloud App User Manual

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
