Sungrow SG50CX User Manual

74
Network Service Provider
Grid Type
SA Power Networks
• TS129-2019: < 10 kW for single-phase
& 30 kW for three-phase
• TS130-2017: > 30 kW & ≤ 200 kW
• TS131-2018: > 200 kW
Horizon Power
• HPC-9DJ-13-0001-2019: ≤ 10 kVA for
single-phase & 30 kVA for three-phase
• HPC-9DJ-13-0002-2019: > 30 kVA &
≤1 MVA
westernpower
EDM＃33612889-2019
AusNet Services Basic Micro Embedded Generation:2020
For compliance with AS/NZS 4777.2:2020, please select from Australia A/B/C. Please con-
tact your electricity grid operator for which region to use.
Step 6 After finishing the settings, tap TUNR ON DEVICE at the upper right corner and the device
will be initialized. The App will send start instructions and the device will start and operate.
Step 7 After initialization settings, the App will return automatically to the home page.
- - End
7.5 Home
After login, the home page is as follows:
7 iSolarCloud App User Manual

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
