Istruction Manual for Operation and Maintenance SPX-960:
1.4 TECHNICAL SPECIFICATIONS
1.4.1 STANDARD MACHINE
DIMENSIONS (see next page)
Length (with rear tow point and bumpers) 6200 mm - 244 in
Shipping width (36” shoes) 3790 mm - 149.2 in
Operating width 4150 mm - 163.4 in
Operating height 3500 mm - 137.8 in
Total working weight 62000 Kg - 136684 Lb
DIESEL ENGINE
Brand CATERPILLAR
Model C13 ACERT
Emissions (ref. stds “Tier 3” according to American standards, “Stage IIIA” according to European stds)
Net fl ywheel power (DIN 6270 - SAEJ 1349) 440 HP - 324 kW
Rev. per minute 2,200 rpm
Displacement 12.5 lt - 763 cu in
Consumption (tentative) 42 l/h - 11 U.S.Gal/h
HYDRAULIC SYSTEM
Main pumps (BOSCH-REXROTH) 2 independent, variable pumps
Max. fl ow rate 2x450 lt/min - 2x119 U.S. gal/min
Max. operating pressure 400 bar - 5,800 p.s.i.
Service pumps 1 tandem gear pump
Max. fl ow rate 50 lt/min - 13 U.S. gal/min
DRIVE
Type hydrostatic, closed circuit, including one pump and two motors per track
Brakes (4) integrated, negative control
Final drives (2) planetary , in oil bath
Speed:
1st speed 1.7 Km/h - 1 miles/hr
2nd speed 2.6 Km/h - 1.6 miles/hr
3rd speed 5.3 Km/h - 3.3 miles/hr
CONTROLS
Type Two-side operation
Safety devices Emergency shut-off
TSSystem: steering wheel complete with 2 additional levers for safer and more precise steering.
1
1-8
PRELIMINARY REMARKS
