Istruction Manual for Operation and Maintenance SPX-960:
4.3.3
CONTROL INSTRUMENTS FEATURED IN OPTIONAL VISIO TERMINAL
The pipe layer SPX-960 is provided with two different versions of the control panel: STANDARD or
VISIO (option).
ATTENZIONE
BELOW IS A SET OF INFORMATION AND INSTRUCTIONS RELATING EXCLUSIVELY TO THE OP-
TION VISIO PANEL. FOR INFORMATION ON THE STANDARD VERSION OF THE PANEL, REFER
TO THE SECTION «4.3.1 STANDARD CONTROL INSTRUMENTS». FOR ANY OTHER CONTROL
FEATURES WHICH DO NOT SPECIFICALLY RELATE TO THE VISIO TERMINAL, REFER TO THE
SECTION «4.3.2 PIPE LAYER CONTROLS».
Key for fi gure 36: control panel featuring optional Visio terminal
1) Left-hand drive control lever.
2) Right-hand drive control lever.
3) Multiple function joystick for combined left- and right-hand drive control.
4) Multiple function joystick for hook and boom control.
5) Counterweight control lever.
6) Diesel engine ignition key.
7) Emergency button (stop).
8) Orange light - diesel engine diagnostic.
9) Horn button.
10) Step button preset at 900 rpm.
11) Step button preset at 1300 rpm.
12) Step button preset at 1800 rpm.
13) Step button preset at 2100 rpm.
14) Progressive throttle button (+) (-).
15) Two-speed selector.
16) Windscreen wiper switch.
17) Light switch unit.
18) Rpm programming button located under the plate (to be used.
by service technicians only).
19) Parking and brake button (for emergency conditions too).
20) Cooling water temperature indicator.
21) Hydraulic oil system temperature indicator.
22) Engine oil pressure indicator.
23) Volt meter.
26) Left-hand drive booster pump gauge.
27) Right-hand drive booster pump gauge.
28) Temperature fuse, 15A.
29) Temperature fuse, 10A.
30) Temperature fuse, 15A.
31) Temperature fuse, 60A.
32) Fuse-holder blocks.
33) Visio control panel (option).
34) Free fall button.
35) Anti-tipping system bypass key.
36) Anti-tipping system power switch.
37) White light - anti-tipping electrical system error.
41) Battery on/off key located on engine hood left-hand side (A = battery OFF; B = battery = ON).
42) Safety lever (drive engaged).
43) Electronically-controlled power unit.
46) PC connector (under plate).
4
4-14
MACHINE OPERATION
