Istruction Manual for Operation and Maintenance SPX-960:
TRACKED CARRIAGE
Tracks with sealed and lubricated chain
Track support rollers 9+9
Track support rollers 2+2
Length of track on ground 2.6 m - 8.5 ft
Track gauge 4.08 m - 13.4 ft
STD shoe width 914 mm - 36 in
Shoe area 73440 cm
2
- 11382 sq in
Optional shoe width 1015 mm - 40 in
Shoe area 82824 cm
2
- 12837 sq in
Chain spacing 260.35 mm - 10.25 in
CAPACITIES
Diesel fuel tank 720 liters - 190 U.S. gal
Hydraulic tank 345 liters - 91 U.S. gal
Engine cooling system 65 liters - 17.2 U.S. gal
Diesel engine oil 34 liters - 9 U.S. gal
Drive circuit 12 liters - 3.4 U.S. gal
ELETTRIC SYSTEM
Operating voltage 24 V
Serial maintenance-free batteries 2
Total capacity 220 Ah
Starter 7.5 Kw
Alternator 55 A
ROPS-FOPS PROTECTION
Rops (ref. standards) EN 13510 - ISO 3471:1994 (1:1997 modifi ed) - SAE J1040
Fops (ref. standards) EN ISO 3449 - SAE J231
Weight 400 Kg -882 Lb
The test is to be considered successful even if the required power values have not been reached. In the
event that the pipe layer tips to one side, it will never touch the ground with the Rops-Fops protection, but
rather with the counterweight rack on one side and the boom on the other
1.4.2 PIPELAYING EQUIPMENT
BOOM
STD boom length 7.31 m - 24 ft
Optional boom length 8.53 m - 28 ft
Wire rope diameter 19 mm - 3/4 in
Min. breaking strength 323 KN - 72,530 lb
Part load line 8
Part boom line 5
1
1-10
PRELIMINARY REMARKS
