Istruction Manual for Operation and Maintenance SPX-960:
Decal 6 (yellow background)
Under no circumstances should the operator start the machine
up if he is not sitting in his seat. The operator must start the
machine after sitting in the drive seat and fastening the seat
belt.
Decal 7 (yellow background)
Do not unscrew the stack valve to reduce track tensioning.
Do not remove the greasing nipple on the registration valve:
follow the procedure provided in the instruction manual. The
spring on the track tensioning wheel is installed with a high
compression. To install or de-install this spring, follow the
procedure provided in the instruction manual.
Decal 8
(yellow background)
Pay great attention when removing the safety bolt during
counterweight disassembly from the frame.
Decal 9 (yellow background)
Pay attention when moving the lifting boom and standing close
to the counterweight. Keep away from moving parts. There is
a risk of cutting the arms and legs.
Decal 10 (yellow background)
Pay attention when moving the lifting boom and blocks. Keep
away from the machine when it is operating. Constantly moni-
tor the area around the machine. Keep unauthorized persons
out of the work area and authorized people at a safe distance
from the machine.
Decal 11 (yellow background)
This decal provides instructions for correct operation of the
anti-two-block.
Decal 12 (yellow background)
The machine produces high levels of noise. The operators
must therefore wear ear muffs in compliance with the relevant
regulations.
STOP
Deal 7
Deal 8
Deal 9
Deal 10
Deal 11
Deal 12
2
Deal 6
2-7
SAFETY RULES
