Fig. 47
1) Boom hinging pins. - 2) Boom support block. - 3) Boom block pin. - 4) Hook block support pin. - 5) Articulated
attachment. - 6) Hook blocks. - 7) Block support pin housing. - 8) Lifting hook.
