X10DRT-B+ Motherboard User’s Manual
X10DRT-B+ Motherboard LED Indicators
LED State
BMC_HB_LED1 (BMC Heartbeat LED) Green (Blinking): BMC normal
LE6 (Onboard Power LED)
Orange: Standby power ready
Green: All power RAMP normal
Red: One or more power regulators failed
UID_LED1 (Rear Unit Identier LED) Blue: (On/Blinking): Unit identied
