1-2
Supermicro C7Z97-OCE Motherboard User’s Manual
1-3 Motherboard Features
CPU
Single 4th Generation Intel® Core™ i7/i5/i3 DT
processors in an LGA1150 socket.
Memory
Four (4) DDR3 slots support up to 32 GB of Unbuf-
fered, Non-ECC 1066~3300MHz(OC) XMP memory*
Dual-channel memory
DIMM sizes
UDIMM 1 GB, 2 GB, 4GB, and 8GB
Chipset
Intel® Z97 Express
Expansion Slots
Three (3) PCI Express 2.0 x1 (in x4) slots
One (1) PCI Express 3.0 x16/x8 (in x16) slot
One (1) PCI Express 3.0 x8/x4 (in x16) slot
One (1) PCI Express 3.0 x4 (in x16) slot
Network
Connections
Two (2) Gigabit Ethernet Controllers:
LAN1: Intel i217 gigabit LAN controller
LAN2: Intel i210 gigabit LAN controller
Two (2) RJ-45 rear I/O panel connectors with Link
and Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Two (2) A-SATA 0~1, via ASM1061
SATA 3.0 (6Gb/s) Four (4) I-SATA 0~3, via Intel Z97
RAID 0, 1, 5, 10
USB Devices
Two (2) USB 2.0 ports and Four (4) USB 3.0 ports
on the rear I/O panel
Four (4) Front-Accessible USB 2.0 ports on Two
headers and two (2) Front Accessible USB 3.0 ports
on one header.
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Other I/O Ports
One (1) DisplayPort, One (1) VGA Port, One (1)
DVI-D Port, One (1) HDMI Port
One (1) Serial Port header (COM1)
*The C7Z97-OCE supports memory modules having a frequency of more than 2133MHz
(Extreme Memory Prole or XMP Memory). However, XMP memory is not within the JEDEC
memory standard. Compatibility and stability of these memory modules depend on varying
factors, including the processor's capabilities and other devices installed.
