Chapter 2: Installation
2-1
Chapter 2
Installation
2-1
Installation Components and Tools Needed
Screws
Phillips-Head Screwdriver
Intel LGA 1150 Pr
ocessor
DDR3 DIMMs
PC Chassis
Heatsink with F
an
P
ower Supply
Video
Card
(Optional)
SA
T
A/USB Optical Drive (Optional)
SA
T
A Hard Disk Drive
30
32
