Supmeter BST106-M10 User Manual

9
3.4 Button Operation
Name Operation State Indicator Authorization
【Auto】 Auto / Manual [Emergency Stop] switch.
Green: Auto state.
Grey: Manual state.
All Users
【Start】 Start.
Green: Running state.
Grey: Stop state.
【Re-run】 Clear Alarm & Recover Running.
【Last】
Last Batch [Normal Stop].
Stop after the present batch finished.
Flashing Red.
【Pause】 Pause.
【E-stop】 Emergency Stop.
【Alarm】
Alarm Query / Clear Alarm.
‘Auto/Pause’ state: Recover Running after
clearing alarm.
Red: Alarm state.
【Mat.】
Material Selection for Auto-Batching.
Mixer in Weighing Hopper
Running Selection
While High-speed Feeding [Only for Single-scale
Mode].
Green/Blue: Selected.
Grey: Unselected.
【Print】
Report Print:
 [ Auto Print]: Print Batch Records.
 [Total]: Print Totalizing Report.
 [Recipe]: Print Working Recipe.
【Lock】
Screen-
locking: Locking/unlocking the operating
buttons of main display interface.
Auto Screen-locking: Refer to parameter [901].
Flashing Red: Locked.
Grey: Unlocked.
【Menu】 Enter Main Menu.
【User】 User Login. Display: Operator / Engineer / Admin.
【Zero】
Zero Fine Adjustment [No Power-down
Protection].
Flashing green.
【High】 Manual Start/Stop Mn High-speed Feeding.
Green: Working state.
【Low】 Manual Start/Stop Mn Low-speed Feeding.
【Dump】 Manual Start/Stop Dumping.
【MixbinDump】 Manual Start/Stop Mixing Bin’s Dumping.
【Mn】 Material Selection for Manual Operation.
【Clear】
Clear Screen: Clear the display values of Feeding
Weight, Totalized Weight and Batch Count’.
Engineer
Administrator
