Supmeter BST106-M10 User Manual

50
6.5.3 AO Assignment
No. Sign Range Default Description REG
727 AO1 Signal 0~4 4
AO1 Signal
0: #1 Gross Weight
1: #1 Net Weight
2: #1 Unused
3: #1 Final Feeding Weight
4: #1 Feeding Control
40755
728 AO2 Signal 0~4 4
AO2 Signal
0: #2 Gross Weight
1: #2 Net Weight
2: #2 Unused
3: #2 Final Feeding Weight
4: #2 Feeding Control
40757
729 AO3 Signal 0~4 4
AO3 Signal
0: #3 Gross Weight
1: #3 Net Weight
2: #3 Unused
3: #3 Final Feeding Weight
4: #3 Feeding Control
40759
730 AO4 Signal 0~4 4
AO4 Signal
0: #4 Gross Weight
1: #4 Net Weight
2: #4 Unused
3: #4 Final Feeding Weight
4: #4 Feeding Control
40761
731
High Feeding
AO
0.00~10.00 5.00
#1 High-speed Feeding AO1 Control Voltage [V] 40763
#2 High-speed Feeding AO2 Control Voltage [V] 40765
#3 High-speed Feeding AO3 Control Voltage [V] 40767
#4 High-speed Feeding AO4 Control Voltage [V] 40769
732 Low Feeding AO 0.00~10.00 2.00
#1 Low-speed Feeding AO1 Control Voltage [V] 40771
#2 Low-speed Feeding AO2 Control Voltage [V] 40773
#3 Low-speed Feeding AO3 Control Voltage [V] 40775
#4 Low-speed Feeding AO4 Control Voltage [V] 40777
