Supmeter BST106-M10 User Manual

36
6.3.5 Timer Parameters
No. Sign Range Default Description REG
400
T1 Delay to Auto
ZERO
0.00
~9.99
2.00
T1 Delay to Auto ZERO [s]
Delay Time Before Auto Zero Fine Adjustment.
If Auto Zero Fine Adjustment (set via parameter
[302]) is not necessary before feeding, the time T1
will not be delayed.
T1 delaying process: If the delayed time is up to 1s,
then once the real-time weight is stable, the T1
delaying process will end immediately.
Refer to
parameter [108] ‘Stablity Judging Range’ and [109]
‘Stablity Judging Time’.
Then the controller will do ‘
Auto Zero Fine
Adjustment’.
40401
401
T2.SP1 No
Comparing Time
0.00
~9.99
0.50
T2.SP1 No Comparing Time [s]
When the process of ‘High-speed Feed’ starts, the
impact of falling materials will make the weighing
hopper vibrating, so it’s prohibitted
to compare
Feeding Weight with SP1 Setpoint in the time
T2.SP1.
40403
402
T2.SP3 No
Comparing Time
0.00
~9.99
0.80
T2.SP3 No Comparing Time [s]
When the process of ‘High-speed Feed’ stops, the
flow sudden-change of falling materials will make
the weighing hopper vibrating, so it’s prohibitted to
compare Feeding Weight with SP3 Setpoint in the
time T2.SP3.
This parameter is invalid to the processes of ‘Auto
SP3 Re-feed’ and ‘Manual SP3 Re-feed’.
40405
403
T3 Delay to
Stabilize Weight
0.00
~9.99
2.00
T3 Delay to Stabilize Weight [s]
When ‘SP3 Low-speed Feed’, ‘Auto SP3 Re-feed’
or ‘Manual SP3 Re-feed’
stops, some materials
have left the feeding hopper but still in mid-air, so
it’s necessary to delay the time T3 for ensuring all
of the materials in mid-air fell into the weighing
hopper.
T3 delaying process: If the delayed time is up to 1s,
then once the real-time weight is stable, the T3
delaying process will end immediately.
Refer to
parameter [108] ‘Stablity Judging Range’ and [109]
‘Stablity Judging Time’.
Then the controller will do Final Feeding Weight
Detection, Deviation calculation and Deviation
alarm.
After the batching process ended, the DO switch
‘Dumping’ will turn on automatically to open the
dumping gate and enter the dumping process.
40407
