Supmeter BST106-M10 User Manual

58
Appendix C. Data Frame Format of Continuous Sending [ASCII]
Table 1
FORMAT START DATA1 DATA 2 … DATA N Checksum END
Character =
See Table 3
CR LF
ASCII 3DH 0DH 0AH
Bytes 1 7 7 7 7 2 2
How to get ‘Checksum’: Add all the ASCII values ahead of Checksum to get a single-byte hexadecimal data, then
conver it to two ASCII values.
Table 2
Character Minus Sign ‘-’ Decimal Digit 0~9 Decimal Point ‘.’
ASCII 2DH 30H~39H 2EH
Table 3
[807] Set Data Name DATA1 DATA2 DATA3 DATA4
[807]=0 Gross Weight Weigher #1 Weigher #2 Weigher #3 Weigher #4
[807]=1
Final Feeding
Weight
Weigher #1 Weigher #2 Weigher #3 Weigher #4
[807]=2 Batch Count Weigher #1 Weigher #2 Weigher #3 Weigher #4
[807]=3 Totalized Weight Weigher #1 Weigher #2 Weigher #3 Weigher #4
[807]=4
Data Name DATA1 DATA2 DATA3 DATA4
Gross Weight Weigher #1 Weigher #2 Weigher #3 Weigher #4
Data Name DATA5 DATA6 DATA7 DATA8
Final Feeding
Weight
Weigher #1 Weigher #2 Weigher #3 Weigher #4
Data Name DATA9 DATA10 DATA11 DATA12
Batch Count Weigher #1 Weigher #2 Weigher #3 Weigher #4
Data Name DATA13 DATA14 DATA15 DATA16
Totalized Weight Weigher #1 Weigher #2 Weigher #3 Weigher #4
Parameter [807]: ‘Data for Continuous Sending Mode’.
