4.3 DI/DO Ex-factory Assignment
[*]: If need this DI function, the user can define it.
DI [Valid with high-level input voltage 24V]
No. Pin Signal Name Description
6 DI1
AUTO
[*]
Auto/Manual.
ON: Auto state.
OFF: Manual state / Emergency Stop.
7 DI2 START
Start.
‘Auto/Stop’ state: Start.
In ‘Auto/Running’ process: Clear Alarm [Deviation Alarm
Acknowledge]
‘Auto/Pause’ state: Clear Alarm & Recover Running.
OFF→ON→OFF.
8 DI3
LAST
Last Batch [Normal Stop].
OFF→ON→
OFF: Stop automatically after the batching
process of the present batch ended.
MIXER_START
[*]
Start Mixer.
OFF→ON→OFF.
9 DI4
DUMP_I
[*]
Manual Dump [#1-4].
ON: Manual Dump.
OFF: Stop.
MIXER_STOP
[*]
Stop Mixer.
OFF→ON→OFF.
10 DI5
BELT_START
Start Mixing Conveyor.
OFF→ON→OFF.
PAUSE
[*]
Manual Pause.
OFF→ON→OFF.
11 DI6
BELT_STOP
Stop Mixing Conveyor.
OFF→ON→OFF.
SP3_I
[*]
Manual SP3 Re-feed.
Valid at Auto-pause state with Mn’s Negativ
e Deviation
Alarm.
ON : Manual SP3 Re-feed.
OFF : Stop.
12 DI7
BELT_RDY
[*]
Mixing Conveyor Ready.
ON: Ready.
OFF: Not Ready.
