4.2.3 Loadcell Terminal
No. Pin Description
LOADCELL Loadcell Port
1 1- Weigher #1 Weighing Signal [mV] Input -.
2 1+ Weigher #1 Weighing Signal [mV] Input +.
3 E- Excitation Voltage -.
4 E+ Excitation Voltage + [DC5V].
5 3- Weigher #3 Weighing Signal [mV] Input -.
6 3+ Weigher #3 Weighing Signal [mV] Input +.
7 P Shield Ground.
8 2- Weigher #2 Weighing Signal [mV] Input -.
9 2+ Weigher #2 Weighing Signal [mV] Input +.
10 E- Excitation Voltage -.
11 E+ Excitation Voltage + [DC5V].
12 4- Weigher #4 Weighing Signal [mV] Input -.
13 4+ Weigher #4 Weighing Signal [mV] Input +.
14 P Shield Ground.
